A Bit of Quantum Logic—What Did the Atom Say to the Quantum Dot?

Let’s talk! Scientists demonstrate coherent coupling between a quantum dot and a donor atom in silicon, vital for moving information inside quantum computers.

Angled view scanning electron microscope image of the device gate structure. The blue overlay represents the electrically active part of the device. The upper left portion of the device serves as a charge sensor (CS) to detect the state of the qubit. Donors are implanted in the regions designated by the dashed red lines. The relevant donor (D) located next to the quantum dot (QD) is indicated by the red dot. Scale bar: 200 nanometers.

The Science

Quantum computers could tackle problems that current supercomputers can’t. Quantum computers rely on quantum bits, or “qubits.” Current computers perform millions of calculations, one after the other. Qubit coupling allows quantum computers to perform them all at the same time. Qubits could store the data that add up to bank accounts and medical records. In an unusual twist, qubits represent data by the binary state of electron spins. Two systems existed to create qubits. Researchers successfully integrated the systems—donor atoms and quantum dots. The new qubits don’t let the spins, and hence the data, degrade. Specifically, the bits demonstrate coherent coupling of the electron spins. This hybrid approach, which has remained elusive until now, exploits the advantages of the two qubit systems.

The Impact

For almost two decades, scientists have created theoretical proposals of such a hybrid qubit (donor qubit) architecture. Now, researchers have made an important step toward the practical realization of silicon qubits. Silicon matters. Why? It is the same material used today in our personal computers. The manufacturing process for qubits could fit within today’s manufacturing and computing technologies.

Summary

Qubits form the basis of quantum computation. Building a practical quantum computer demands two important features: the maintenance of coherent quantum states and the assembly of qubits. Coherence can be thought of as an ideal property of the interacting wavefunctions that describe particles. Silicon is an appealing qubit material as it provides an environment that minimizes quantum decoherence. Additionally, there is already infrastructure in place for building silicon devices. However, the second critical requirement—assembling the qubits—has proven immensely challenging. Donor atoms must be embedded in silicon in such a way that their interactions can be controlled. Achieving this demands extreme precision. A collaboration between scientists from Canada, Sandia National Laboratories, and the Center for Integrated Nanotechnologies has uncovered an alternative to this donor coupling arrangement—by using quantum dots (QDs). In a cornerstone advance, the researchers demonstrated coherent coupling of the electron from a phosphorus donor atom and an electron of a metal-oxide semiconductor QD. This approach is advantageous. It does not require the extreme degree of placement accuracy as donor coupling. The electronic states of this system are controlled by the nuclear spin of the donor atom, providing a simple integrated method for interacting with the qubit. Thus, there is no need to use additional micromagnets or QDs.

Contact

Michael Lilly
Center for Integrated Nanotechnologies, Sandia National Laboratories
mplilly@sandia.gov

Funding

This work was performed, in part, at the Center for Integrated Nanotechnologies, a user facility operated for the Department of Energy (DOE) Office of Science. Sandia National Laboratories is a multimission laboratory managed and operated by National Technology and Engineering Solutions of Sandia, LLC, a wholly owned subsidiary of Honeywell International, Inc., for DOE’s National Nuclear Security Administration.

Publications

P. Harvey-Collard, N.T. Jacobson, M. Rudolph, J. Dominguez, G.A. Ten Eyck, J.R. Wendt, T. Pluym, J.K. Gamble, M.P. Lilly, M. Pioro-Ladrière, and M.S. Carroll, “Coherent coupling between a quantum dot and a donor in silicon.” Nature Communications 8, 1029 (2017). [DOI: 10.1038/s41467-017-01113-2]
